Δύο νέα μοντέλα οθονών στις 23”, με τη νέα RadiForce MS235WT, το φρέσκο multitouch μοντέλο στη σειρά RadiForce MX εμφανίστηκαν από τη γνωστή εταιρία για ‘ιατρική’ χρήση.
Η δε MX Series έχει σχεδιαστεί για ένα περιβάλλον χωρίς φιλμ και ιατρικές εικόνες DICOM με το multitouch να επιτρέπει tap, scroll, drag, pinch, spin, και άλλα.
Το multitouch interface υποστηρίζει Windows 8 και 7 αλλά και άλλα OS. Η δε RadiForce MS235WT έχει υψηλά specs και επιτρέπει tilt για χρήση με φωτισμό LED backlight.
Specification of Eizo RadiForce MS235WT
Cabinet Color Black, Gray
Panel
Type TFT Color LCD Panel (IPS)
Backlight LED
Size 58 cm / 23″ (584 mm diagonal)
Native Resolution 1920 x 1080 (16:9 aspect ratio)
Display Size (H x V) 509.1 x 286.4 mm
Pixel Pitch 0.2652 x 0.2652 mm
Display Colors 8-bit colors: 16.77 million from a palette of 1.06 billion colors
Viewing Angles (H / V, typical) 178°, 178°
Brightness (typical) 260 cd/m2
Contrast Ratio (typical) 1000:1
Response Time (typical) 16 ms (On/Off), 6 ms (Midtone)
Touch Panel
Type Projected Capacitive Type
Communication Protocol USB
Surface Hardness 5 H
Compatible OS Multi-touch: Windows 8 (64-bit, 32-bit), Windows 7 (64-bit, 32-bit)
Single-touch: Windows XP (32-bit)
Video Signals
Input Terminals DVI-D x 1, DisplayPort x 1, D-Sub mini 15 pin x 1
Digital Scanning Frequency (H / V) 31 – 68 kHz / 59 – 61 Hz (VGA Text: 69 – 71 Hz)
Analog Scanning Frequency (H / V) 31 – 81 kHz / 55 – 76 Hz
Sync Formats Separate
USB
Function 1 upstream, 2 downstream
Standard Rev. 2.0
Audio
Speakers 1.0 W + 1.0 W
Input Terminals 3.5 mm stereo jack, DisplayPort
Output Terminals 3.5 mm headphone jack
Sound Adjustment Volume, Source (DisplayPort)
Power
Power Requirements AC 100 – 120 V, 200 – 240 V: 50 / 60 Hz
Maximum Power Consumption 56 W
Typical Power Consumption 21 W
Power Save Mode Less than 0.5 W
Power Management Digital: DVI DMPM, DisplayPort 1.1a
Analog: VESA DPM
Features & Functions
Brightness Stabilization Yes
Preset Modes CAL-Switch
OSD Languages English, German, French, Italian, Japanese, Simplified
Chinese, Spanish, Swedish, Traditional Chinese
Physical Specifications
Net Weight 6.6 kg
Net Weight (Without Stand) 6.0 kg
Hole Spacing (VESA Standard) 100 x 100 mm
Certifications & Standards (Please contact the EIZO group company or distributor in your country for the latest information.) CE (Medical Device Directive), EN60601-1, UL60601-1, CSA C22.2 No. 601-1, IEC60601-1, VCCI-B, FCC-B, Canadian ICES-003-B, C-tick, RoHS, China RoHS, WEEE, CCC, GOST-R
Supplied Accessories AC power cord, signal cables (DVI-D – DVI-D, DisplayPort – DisplayPort), USB cable, audio cable, touch pen, holder for touch pen, Utility Disk (user’s manual), cleaning cloth
Warranty Three Years
Dimension Drawing PDF
